Introduction of the cannon tube
Here's an introduction to the cannon tube
Definitions and Uses
Definition: The air cannon pipe is a kind of pipe used to connect pneumatic equipment and air pump, and its main function is to transport the compressed air generated by the air pump to air tools such as air picks, air picks, and air cannons, so that these tools can work normally.
Uses: Widely used in industrial construction, auto repair, construction, mining and other fields, such as tire disassembly and installation in automobile maintenance, assembly and disassembly of industrial equipment, crushing operations in building construction, etc.
Performance characteristics
High pressure resistance: The air cannon tube can withstand high air pressure, the general working pressure is about 60KG, and the burst pressure can reach 200KG, ensuring that there will be no rupture or leakage during the high-pressure gas transmission process.
Cold and heat resistant: The high-quality air cannon tube will not be brittle in a low temperature environment, and will not soften and deform in a high temperature environment. For example, some air cannon tubes can work well in temperatures ranging from -28°C to 60°C, adapting to a variety of harsh working environments.
Good flexibility: The air cannon tube has a soft texture, which is easy to bend and operate, can adapt to various complex construction scenarios, and is convenient for workers to move between different stations.
Selection and Maintenance
Selection method: When selecting the air cannon tube, it is necessary to select the air cannon tube with suitable pressure resistance and flow capacity according to the working pressure, flow rate and other parameters of the pneumatic tool. At the same time, it is also necessary to consider the working environment, such as temperature, humidity, whether there are corrosive substances, etc., and choose the corresponding cold-resistant, oil-resistant, corrosion-resistant and other performance of the wind cannon tube.
Maintenance: Regularly check the appearance of the air cannon tube to see if there is any damage, aging, hardening and other phenomena; Clean the dirt and oil on the surface of the trachea to avoid corrosion of the trachea; Check whether the joint of the trachea is loose, and tighten it in time if it is loose.
FAQ
Q:What parameters should be checked for excessive expansion of the tube during ventilation?
A: Whether the working pressure exceeds the rated value, whether the thickness of the pipe wall is up to the standard, or whether the density of the braid layer is insufficient.
Q: What could be the problem with a significant drop in flow after frequent bending?
A: The internal pipeline is deflated, the wire layer is broken and blocked, or the joint is stuck.
Q: What factors should be investigated if the pressure loss is too large after connecting with the air compressor?
A: The pipe is too long and the diameter is too small, the joint diameter is not matched, or there are debris blockages in the pipe.
