The pneumatic nail gun is a tool that uses compressed air as a power source to drive. The principle of operation is relatively simple and efficient, the trigger switch makes the firing pin reciprocate in the cylinder, and then the nail is sent to the cover groove with the help of a compression spring or tension spring, and when the firing pin comes out of the nozzle, the nail is struck. Pneumatic straight nail guns obtain compressed air by connecting an air source, such as an air compressor. After the compressed air enters the gun body, the cylinder of the pneumatic straight nail gun that provides the required power for the nail shooting process is the main component of the compressed air, and the compressed air pushes the firing pin motion in the cylinder. His firing pin: under the action of the cylinder, it does high-speed repetitive movements, and pushes the nail directly out of the nozzle to achieve the nailing function. Magazine: used for loading straight nails, generally there are two kinds of fixed magazines and movable magazines, the common magazine loading capacity ranges from dozens to hundreds, such as the Milwaukee M18 16GA straight nail gun has a magazine loading capacity of 110 nails. Trigger: It is a part that controls the nailing action, and the user starts the nailing operation by pulling the trigger. Air nozzle: connect the air source to allow the compressed air to enter the inside of the gun body.
Product parameters
| Model: | F30B |
| Groove capacity: | 100 pcs |
| Nail Length： | 10-30 mm |
| net weight： | 1.1kg |
The pneumatic straight nail gun is characterized by strong power, using compressed air as the required power, which can provide a large nailing force, and can drive the straight nail into wood, plastic and other materials more quickly and firmly, for example, in furniture manufacturing, it can easily splice and fix wooden boards. The pneumatic straight nail gun has high efficiency, can be continuously and quickly nailed, which greatly improves the work efficiency of workers, and can quickly complete a large number of nailing work in the decoration project, and saves time, manpower and material resources. The straight nail gun is easy to operate: the operation is relatively simple, you only need to aim the nozzle at the work object, and pull the trigger to complete the nailing action, which does not require complex operation skills, and it is easy for novices to get started. High accuracy, designed with a precise positioning system and a stable shooting mechanism, can allow the operator to place each nail more precisely, to ensure that the nail position is accurate, especially suitable for work with high precision requirements.
Product details display
The pneumatic straight nail gun has a wide range of applications, which can be used for fixing a variety of materials, such as wood, gypsum board, plastic, etc., and has a wide range of applications in many industries such as construction, decoration, furniture manufacturing, and packaging.
FAQ
Q: How to quickly deal with a stuck nail?
A: Immediately cut off the gas, use a special tool to pry open the nail channel and remove the card nail, clean the residual wood chips, and check whether the nail groove is deformed.
Q: Can different lengths of straight nails be mixed?
A:It is necessary to match the machine calibration range (such as 10-30mm). If it exceeds the range, use easy to get stuck nails or damaged nail tracks. The same specifications but different brands can be used interchangeably.
Q: How to store without long-term use?
A:Exhaust the remaining air from the exhaust pipe, drop 2-3 drops of pneumatic lubricating oil into the air inlet, empty it several times, store it in a dry place and cover it with a dust cover.
