| Rated power | Blade speed | Blade size | Maximum cut size |
| 1100W | 0.7-2.4m/s | 1141*13*0.65mm | 115mm |
Band saw series is a kind of machine that uses an annular endless saw blade around two saw wheels and a continuous rotary motion in the same direction to carry out sawing. The saw blade rotates at high speed under the drive of the saw wheel, and the cutting of the material is realized through the contact friction between the saw tooth and the material.
According to the process requirements: log band sawing machine, is the main saw of the band sawing timber factory, used for log cutting and sawing board square timber, usually using sports car band saw machine or double log band sawing machine; The band sawing machine is divided into the main band saw machine that divides the rough square into plate square timber and the plate belt saw machine that divides the plate skin into thin plates. According to the rotation direction of the saw wheel, it is divided into a right-handed band saw machine that rotates clockwise and the wood is sawed from the right side; Left-handed band saw machine with counterclockwise rotation and wood sawing from the left side, according to the saw blade tensioning device: double-column lever ordinary tensioning device band sawing machine; Hydraulic pressure high tension cantilever band saw, its tension force is 2-3 times that of the former.
According to the relative position of the two saw wheels, it is divided into: vertical bandsaw machine, horizontal bandsaw machine and inclined bandsaw machine. Horizontal band saws are only used in China to split the bark into burr-edged boards, and in other countries they are also used to sawn precious hardwood logs. According to the presence or absence of chipping cutter heads: ordinary band sawing machine without chipping cutter head, sports car band saw machine equipped with single chipping cutter head, double and quadruple band saw machine equipped with double disc chipping cutter head. The main body of the band saw machine: it is composed of the machine body, two saw wheels, a tensioning device, a saw wheel lifting and pitching device, a saw card, a safety cover, etc. Among them, the lower saw wheel is the driving wheel, and the upper saw wheel is the driven wheel. Sports car: It is composed of upper log device, wood turning device, track and transmission running device, sports car body stuck wood device, shaking ruler device, pile fine-tuning device, car pendulum, unloading and connecting plate device, etc.
The application field of band saw series is wood processing: it is suitable for log cutting, sawing large slabs into thin boards or small squares, cutting raw edges into whole boards or square timbers, etc., and is also commonly used for cutting and processing wood in furniture manufacturing, building decoration and other industries. Metal processing field: It can be used in the cutting of metal materials such as steel and aluminum, and is widely used in machinery manufacturing and repair, auto parts production, metal products processing, pipes and valves, manufacturing aerospace and other industries.
FAQ
Q:How to quickly adjust the saw blade deviation?
A: After stopping, adjust the position of the guide wheel, fine-tune the tension knob, and calibrate it after the saw.
Q:What should I do if the band saw machine feeds stuck?
A: Clean the debris of the guide rail, check the pressure of the feed wheel, and add lubricating oil to reduce friction.
Q: Can a bimetallic band saw blade cut stainless steel?
A: Yes, but the feed rate needs to be reduced to avoid overheating and wear of the teeth.
